Portfolio

Products

Mozzarella, Buffalo Mozzarella, Pizza Cheese , Kashkaval, Analogue Mozzarella, Processed and Spread Cheese

It is suitable for processing fresh and industrial block of curd, buffalo curd, powders , rennet casein, starch and vegetable or animal fat



ADVANTAGES:

  • Possibility to use fresh and industrial curd, powders ingredients, spices and flavours

  • More production yield than the traditional systems by hot water

  • There will not be more fatty liquid to be purified as all water added is absorbed by the product during steam stretching

  • Stretching by direct steam injection in the product or into the jacket

  • Reduction of heating and stretching time thanks to the steam injection

  • Significant energy saving by reducing steam consumption

  • Standardization of moisture in the final product

Technical Features

  • Entirely built in AISI 316 stainless steel, double wall vat for the steam injection into the jacket
  • The product stretching – melting happens by direct steam injection, or with steam injected into the jacket
  • N. 2 bi-directional augers activated by N. 2 independent motor reducers (mod. Sew- eurodrive – low consumption) with adjustable speed by Inverter
  • Parts that come into contact with the product are shot-peened with quarz microspheres and the augers feature Teflon coating
  • Thermoregulator with digital display for temperature control
  • Autonomous CIP washing system, incorporated in the machine
  • Electrical control panel in AISI 304 stainless steel equipped by a “touch screen” panel and PLC Siemens
  • Easy use of the machine thanks to recipes set in the PLC
  • Filter to sterilize steam complete with filtering cartridge
  • Product unloading by pneumatic exit door

OPTIONAL:

  • Weighing load cells for ingredients quantity control
  • Motorized loading product hopper
  • Automatic Water Liter-counter
  • Remote assistance via internet

Technical data

Hourly production:375 kg/h
125 kg/batch
Dimensions:cm 170x80x240 h
Weight:650 kg
Electrical power:7,5 kW
Material:AISI 316 stainless steel
Operating pressure:0,5 bar
Steam consumption:100 kg/h

SANITISATION

The machine is manufactured according to current regulations on hygiene and sanitisation.
